GTMEDIA V8 Finder Meter V-73 HD (DVB-S2/S2X) |
| ID |  |
| Highlight | 1.Measurements of DVB-S/S2/S2X signals, Hardware decoding; |
| 2.Digital satellite finder meter for quick setup of satellite dishes, |
| 3.3.5 Inch High Definition LCD Screen, |
| 4. Li-Ion battery (7.4 V /3000 mAh) for up to 4-hour operating time. |
| 5.Support AV in and AV/HDMI out function, |
| 6.Support 13V / 18V / LOCK status panel LED display directly, |
| 7.Support for DiSEqC1.0/1.1/1.2/USALSand 22 kHz Tone |
| 8. LNB short circuit protection |
| 9.Support battery power display, |
| Hardware parameters | CPU | Ali M3S10 MPEG-4、MPEG-2、 |
| DDR | 1G DDR3 |
| Flash | 64M SPI |
| Demodulation | M1502+Tuner M3031 |
| Hardware | Video Decode | MPEG-2 MP@HL;MPEG4, BP MP&HP@L4.1;AVS profile@L6.1/4.0/2.0 HDMI:480i/p,576i/p,720p,1080i ,1080P |
| Audio Decode | MPEG1 layer I, MPEG1 layer II, MPEG1 layer III, MPEG2 AAC, MPEG4 HE-AAC,Dolby |
| Panel display | 3.5 Inch LCD Screen |
| LED Indicator | status panel LED display |
| Button | 28 key operation |
| Rear Panel | LNB IN (Frequency Range950MHz to 2150MHz) |
| HD OUT |
| AV OUT (4-pin 3.5 mm * 14MM jack) |
| AV IN (4-pin 3.5 mm * 14MM jack) |
| 1*USB port ( Software upgrades for USB) |
| Power (Input 110V ～240V, 50/60Hz DC12V/1.5A) |
| Standard | System capabilities | DVB-S/S2/S2X system standard:ETS 302 307 |
| LNB Input | Connector | F type,male |
| Frequency range | 950MHZ-2150MHZ |
| Input Impedance | 75Ω |
| Input Signal level | -65dBm~-25dBm(average power) |
| Active Ant Power | 13/18V DC @ 400mA MAX,Overload Protection |
| DiSEqC | DiSEqC1.0/1.1/1.2/USALS Motor fully support |
| LNB switch control | 22K |
| Demodulator | Front end | QPSK,8PSK | | | | |
| Symbol rate | 2Mbps~45Mbps |
| SCPC and MCPC Capable | Yes |
| Spectral inversion | Auto conversion |
| DVB-S Spectrum | Forward error correction rate | 1/4,1/3,2/5,3/5,2/3,3/4,4/5,5/6,8/9,9/10 |
| Carrier frequency acquisition range | ±5MHz for symbol rates above 3 Msps and ±3MHz for the remaining symbol rates |
| Roll-off factors for pulse shaping | 0.2, 0.25 and 0.35 |
| Symbol Rates | 1- 55 Msps |
| Code Rates | 1/2, 2/3, 3/4, 5/6, 7/8 |
| Sortware Features | OSD Language | OSD Multi-language for options (English\German\French\Portuguese\Spanish\Italian\Russian\Turkish\Polish\Arabic \Farsi\Espanol\Deutsch) |
| Channel Search | Channel search in automatic, manual and network search |
| Easy Menu | Plug and Play installation, with an easy to use Menu System |
| PAL/NTSC | Automatic PAL/NTSC conversion, and 4:3 or 16:9 display form |
| SoftUpgrade | Software upgrade through USB |
| Packing | Product Dimension | 95*155*45 MM（L*W*H） |
| Packaged Size | 240*180*58MM |
| Unit Weight | 0.85Kg Kg with gift box |
| Accessories | Digital satellite meter, Adapter,AV cable,Car charger cable, Carrying bag 8.strap of carrying bag,User Manual |
| Physicals | Power Supply | AC IN110-240V, DC 12V/1500mAh |
| Li-oN Battery | Battery 3000mA/7.4V |
| Temperature | Operation 0～+45℃; Storage -10~+60℃ |
| Humidity | 20~90%, non-condensed |
